Description
| Connector type | Screw |
| Contact material | Silber |
| Contact type | Normally Open |
| Current rating | 20 Amps |
| Mounting type | DIN Rail Mount |
About this item
- HELLA produces more than 100 million units per year in its own production facilities
- OE quality: versatile and reliable
- Rated load, rated switching current: Up to 20 A, normally open contact: Up to 10 A, normally closed contact
- Temperature range from: -25°C – Temperature range to: 80°C – Adjustment range from: 0s – Adjustment range to: 900s
- Switch-off delay
- Adjustment Range [sec.]: 0-900
- Adjustment Range [min.]: 0-15
- Temperature range from [°C]: -25
- to temperature range [°C]: 80
- Inspection Tag: e1 033795
Technical Details
Manufacturer ‎Hella KGaA Hueck & Co. Brand ‎Hella Model ‎5HE 996 152-131 Product Dimensions ‎3.8 x 3.8 x 7.5 cm; 31.75 g Item model number ‎5HE 996 152-131 Manufacturer part number ‎5HE 996 152-131 OEM Part Number ‎EVOBUS 003 544 68 32; EVOBUS A0035446832; HUMBAUR 411.00274; HYSTER 4221539; JUNGHEINRICH 51081505; KRONE 0303769/0; LIEBHERR 1 100 158 5; LINDE 7919095031; MANITOU 52564855; MERCEDES-BENZ 221 906 66 00; MERCEDES-BENZ A 221 906 66 00; ROSENBAUER 8612278-001; ROSENBAUER FE3093; SOLARIS 1082-007271-00; STILL 7916291290; STILL 7919095031; TEREX 17AB16-69870; VOLVO 1 522 396 7; VOLVO 15223967; WEIRO 28075; YANMAR 17AB16-69870 // 0035446832; 11001585; 2219066600; A2219066600; 15223967 Lift type ‎Manuell Wattage ‎1 watts Item Weight ‎31.8 g
